Brief Introduction
Sawdust Pelleting Machine is a new biomass fuel production machinery by using crushed sawdust and bran from eucalyptus, pine, birch, poplar, fruit and agricultural straw, bamboo Compared with the old machine ,it absorbed the essence of horizontal ring die and flat die
pellet machine ,solved the insufficient pressure ,die crack problems of horizontal ring die pellet machine ,and overcame the small capacity ,high failure rate of flat die pellet machine .
Wood Pellet Production Line
1. Crushing process:
Wood crusher which can crushed the raw material into sawdust shape ,under 6mm,which is suitable for the dryer and pellet machine.It can crush straw,stalk,tree branches,nutshell,wood shavings,wood waste board,leaves,palm fiber ,etc.
2. Drying process
Air flash wood dryer or drum wood dryer which can dry the material under the moisture of 8%,which is suitable for pellet forming.The dryer use hot air accompany with material and evaporated rapidly .
3. Wood pellet machine:
Wood pellet machine convert the biomass material into pellet ,the length can be customed.
4. Cooling process
You can use a cooling fan or cool it by nature about half or one hour
5. Packing and bagger:
After cooling the semi-automatic quantative packing machine can pack the pellet into bag with quantative weight.
- Place of Origin: China
- Brand Name: Zhangqiu Yulong Machine CO.,LTD
- Model Number: XGJ
Detailed Product Description
Product Name: | Pelleting Machine | Application: | Biomass-energy Fules Plant, Power Plant, Wood Processing Plant |
---|---|---|---|
Pellet Size: | 4-12mm | Power: | 90kw |
Output: | 1-1.5t/h | Weight: | 5.3t |
Color: | White,gray,yellow | Type: | Vertical Ring Die |
Dimension(L*W*H): | 2600x1300x2300mm | Material: | Alloy Steel |
Technical Parameters
Model | Power (kw) | Capacity (kg/h) | Weight (ton) |
XGJ560 | 90 | 1-1.5 | 6.7 |
XGJ850 | 220 | 2-3 | 14.5 |
XGJ920 | 315 | 3-5 | 18 |
XGJ1050 | 450 | 5-6 | 29 |
If you are interested in pellet machine ,please do not hesitate in contact
with us .
